Honda CB125R

ENGINE AND DRIVE TRAIN
Cylinders
1
Strokes
4-Stroke
Valves per cylinder
4
Valves
DOHC
Cooling
liquid
Displacement
125 ccm
Bore
57.3 mm
Stroke
48.4 mm
Max. Power Output
15 HP
Rpm at Max. Power Output
10000 rpm
Max. Torque
11.6 Nm
Rpm at Max. Torque
8000 rpm
Compression Ratio
11.3
Fuel system
Injection
Starter
Electric
Clutch Type
Multiplate in oil-bath
Ignition
Transistor
Final Drive
Chain
Transmission Type
Gearshift
Number of gears
6
CHASSIS
Frame
Steel
Frame type
Central tube
Steering axis angle
24.2 degree
Trail
90.19 mm
SUSPENSION FRONT
Front suspension
Upside-Down telescopic fork
Technology
Big Piston
Diameter
41 mm
SUSPENSION REAR
Rear suspension
Swing arm
Shock absorber
Monoshock
Adjustment
Preload
BRAKES FRONT
Front brake
Single disk
Diameter
296 mm
Piston
Four pistons
Technology
radial
Brand
Nissin
BRAKES REAR
Rear brake
Disc
Diameter
220 mm
Piston
Single piston
ASSISTANCE SYSTEMS
Assistance systems
ABS
DIMENSIONS AND WEIGHTS
Front tyre width
110 mm
Front tyre height
70 %
Front tyre diameter
17 inch
Rear tyre width
150 mm
Rear tyre height
60 %
Rear tyre diameter
17 inch
Length
2015 mm
Width
820 mm
Height
1055 mm
Wheelbase
1345 mm
Seat Height from
816 mm
Kerb Weight (with ABS)
130 kg
Fuel Tank Capacity
10.1 l
License
A1

All information is supplied without guarantee. Errors and clerical errors reserved.
